Explaining Tyre Markings - Tyres Shrewsbury

Explaining Tyre Markings - Tyres Shrewsbury

This data is displayed in the form of various signs, which could be perplexing if you're not sure what you're searching for. Understand what the tyre is informing you with this useful tutorial on Tyres Shrewsbury markings.

New Label for Tyres

The revised tyre label operates as follows:

The three components of the new label are the same as those of the previous one, which was established in 2012: fuel economy, wet grip ability, and sound.

The original A to G grades has been substituted with a value up to E, simplifying the system.

The image of decibels has also been changed. Instead of the rating being displayed as a three-point scale, one of the characters A, B, and C is now emphasized in the audio columns.

What Is the Definition of Tyre Load Rating?

This rating shows the maximum load a tyre may bear, as the name implies.

tyres with a load rating of 91, for instance, can handle 615 kilos. Multiply it by four to get 2,460kg, which is the maximum available load the vehicle can carry. This comprises the vehicle's weight.

Overcrowding a vehicle might jeopardise your security and lead to an accident. It also has an impact on handling and fuel efficiency.

The Meaning of Tyre Marks

In corresponding to the major classifications, each tyre is imprinted with alphanumeric characters that provide enough data for you to select the best one for the vehicle and demands.

The breadth, sidewall thickness, size, shape, load index, and speed limit of a tyre are all represented by the marks.

The diameter of the tyre is indicated by this series of numbers (in this case, 255/55 R16). This is critical because any tyres you install on your Car Tyres Shrewsbury must be the exact size as mentioned in the vehicle's owner's manual. The following are the meanings of the tyre figures:

The Meaning of Tyre Marks

255 – Width of the Tyre

That's the width of the tyre in mm.

55- Tyre's Aspect Ratio

These numbers represent the length of the sidewalls as a percentage of the diameter of the tyres. The tyre's height in this case is 55 percent of the width.

R stands for tyre Design.

The symbol ‘R' denotes that it is radial in structure, as are the majority of modern tyres. Other building styles are ‘B' (bias belt) or ‘D'(diagonal).

16 – Diameter of the Wheel

This number signifies the diameter of the wheel to which the tyres will be mounted in inches.

Speed Rating

It is represented by a symbol, such as ‘V,' and specifies the highest speed at which a tyre can operate while bearing its maximum weight. The letter of the speed classification corresponds to the speed stated in mph or km/h. Because the tyre has a speed classification of ‘V,' the top speed is 240 km/h.

More Information on tyre Markings

1. Brand Name

The name of the tyre's manufacturer will be prominently displayed. This is frequently the biggest inscription on the tyre.

2. Pattern Name

Tyre producers provide a variety of patterns for their tyres. On the wall of the tyre, the patterns of the tyre would be visible.

3. Manufacturer's Country

The lettering on the sidewall can tell you where it has been made.

4. Indications of Tread Wear

Tread Wear indicator would be placed in the grooves instead of on the sidewalls. They could be the characters ‘TWI,' a little image or emblem, or other indications. Once the tyre wear is near to the required limit of 1.6mm these would be seen.

5. Date of Production Code

The date the tyre was made is shown as a series of numbers or letters that appears like DOTXXXXXXXX1017. The very last four numerals correspond to the tyre's manufacturing date, allowing you to determine its age. The date tag, in this case, is 1017, indicating that the tyre was produced in the tenth week of the year 2017.

6. ECE Category Approval in Europe

This means the Tyres Acton Round has been thoroughly tested and meets European safety requirements. The digit after the E is a symbol that indicates the nation the tyre was authorised in. E11 indicates that the tyre is authorized in the UK in this case.
